? Lowest I2
t for greatest protection of semiconductor circuits
? Low watts loss for cooler operation
? Superior cycling ability gives an equipment design advantage
? State-of-the-art protection for 500V equipment
? Ultra compact sizes allow down-sizing of existing equipment
A50QS Amp-Trap? Form 101 fuses grew out of the need to improve the overall
performance of semiconductor fuses in response to new equipment requirements.
The A50QS encompasses the best protection features – lower I2t to provide better
protection for equipment, longer life when subjected to cyclic loading and lower
watts loss. A50QS is today’s best choice for the protection of dynamic solid state
equipment such as motor drives, inverters, UPS, etc.
Highlights:
? 500V AC/DC rated
? Lowest I2
t
? Low watts loss
? Superior cycling ability
Applications:
? Protection of 500V or less motor
drives, UPS, inverters, etc.
A50QS Semiconductor Protection Fuses

 A 50 QS 250 - 4
Amp-Trap? Fuse
Rated Volts - 500

Style
Amperes*
Mounting Types*
Blades, bolt-in
* For ampere ratings and styles not listed, call Technical Services at
978-465-4853.
A
50
QS
250
4
Werma     Flashing light element 24VDC RD    灯秒报价 Catalog Numbering System
Ratings:
Volts : 500VAC / DC
Amps : 35 to 60A (AC)
: 70 to 1200A (AC)
: 35 to 1200A (DC)
I.R. : 200kA I.R. AC
: 87kA I.R. DC
Single Pole Fuse Blocks
for A50QS Fuses
Fuse
Ampere
Rating
Mounting
Type Catalog No.
德国ASM WS17KT-3000-420A-L10-MW-WH 位移传感器35-200 4 P243E
225-600 4 P266C
700-800 4 1SC375
900-1200 4 FH5OF5*
 *(not UL)
For the most current product performance data visit ep.mersen.com and use catalog search. D7
D
Dimensions
Catalog Numbers (amps)
* For ampere ratings and styles not listed, call
Technical Services at 978-465-4853.
A50QS Semiconductor Protection Fuses
A50QS35-4 A50QS250-4
A50QS40-4 A50QS300-4
A50QS50-4 A50QS350-4
A50QS60-4 A50QS400-4
A50QS70-4 A50QS450-4
A50QS80-4 A50QS500-4
A50QS90-4 A50QS600-4
A50QS100-4 A50QS700-4
A50QS125-4 A50QS800-4
A50QS150-4 A50QS900-4
A50QS175-4 A50QS1000-4
A50QS200-4 A50QS1200-4
A50QS225-4
Catalog Number Mounting
Type
Dimensions - Inches (mm)
A B C D E F G H
A50QS35 to 100 4
3.63 1.00 2.13 2.94 2.75 0.31 0.75 0.13
(92.2) (25.4) (54.1) (74.7) (69.9) (7.9) (19.1) (3.3)
A50QS125 to 200 4
3.63 1.22 2.13 2.94 2.81 0.31 1.00 0.19
(92.2) (31.0) (54.1) (74.7) (71.4) (7.9) (25.4) (4.8)
A50QS225 to 400 4
4.34 1.50 2.09 3.41 2.78 0.41 1.00 0.25
Flashing light element 24VDC RD    灯秒报价 (110) (38.1) (53.1) (86.6) (70.6) (10.4) (25.4) (6.4)
A50QS450 to 600 4
Werma     Flashing light element 24VDC RD    灯秒报价 1.50 0.25
(114) (50.8) (56.4) (89.7) (73.9) (10.4) (38.1) (6.4)
A50QS700 to 800 4
6.47 2.38 2.22 5.00 3.44 .53 2.00 .38
(164.3) (60.3) (56.4) (127.0) (87.3) (13.5) (50.8) (9.8)
A50QS900 to 1200 4
6.97 2.88 3.22 5.47 4.47 .63 2.38 .44
(177.0) (76.2) (81.8) (138.9) (113.5) (15.9) (60.3) (11.1)
D8
Features/Benefits:
? Low I2
t minimizes damage to protected components on short circuit
? Controlled arc voltage reduces stress to circuit components during fuse clearing
? Choice of mounting types helps in equipment design
A50P Amp-Trap? Form 101 Semiconductor Protection fuses were developed
for DC drives, uninterruptable power supplies and similar applications requiring
better protection (lower I2
t) and superior reliability. The A50P is typically used for
replacement.
Highlights:
? Very fast acting
? Current limiting
? Low I2
t
? Indicator options available
Applications:
? Protection of DC drives, UPS and
other equipment of 500 volts
or less
Approvals:
? UL Recognized Component
UL File 60314
? AC: UL Guide No. JFHR2
(10-800A)
? DC: UL Guide No.JFHR2
(35-800A)
* Contact technical services
Flashing light element 24VDC RD    灯秒报价 for applications data.
Ratings:
德国ASM WS17KT-3000-420A-L10-MW-WH 位移传感器Volts : 500VAC
: 450VDC
Amps : 10 to 1200A (AC)
: 35 to 1000A (DC)
I.R. : 100kA I.R. AC
: 79kA I.R. DC
L/R : 10ms

 A 50 P 100 - 4 TI
Amp-Trap? Fuse
Rated Volts - 500

Style
Amperes*
Mounting Types*
Ferrule
Blades, bolt-in
Integral Blown-Fuse
Indicator
Trigger Indicator (see pg. J5)
Trigger Actuator (see pg. J5)
* For ampere ratings and styles not listed, call Technical Services at
Flashing light element 24VDC RD    灯秒报价 978-465-4853.
A
50
P
100
1
4
TI
TA
Catalog Numbering System
Single Pole Fuse Blocks for A50P Fuses
Fuse Ampere
Rating
Mounting
Type
Fuse Block
Catalog No.
10-30 1 70316
35-60 4 P243G
70-200 4 P243E
225-600 4 P266C
700-800 4 1SC375
900-1000 4 FH50F5* *(not UL)
A50P Semiconductor Protection Fuses
For the most current product performance data visit ep.mersen.com and use catalog search. D9
D
Catalog Numbers (amps)
Figure 3 Figure 4 Figure 1
Figure 2 Figure 5 Figure 6
* Use with 60306J fuse block.
** Optional Trigger Actuator (TA)
*** Mounting hole is round,
 diameter F.
Dimensions
Outline
Ref.
Mounting
Type Fig.
Dimensions - Inches (mm)
A B C D E F G H
A50P10 to 30 1 1 2.00 0.56 - - - - - -
(50.8) (14.2) - - - - - -
A50P35 to 60 1DS* 1 2.25 0.81 - - - - - -
(57.2) (20.6) - - - - - -
A50P35 to 60 4 2 3.19 0.81 1.63 2.50 2.25 0.34 0.72 0.13
(81.0) (20.6) (41.4) (63.5) (57.2) 8.6) (18.3) (3.3)
A50P70 to 100 4 3 3.63 1.00 2.13 2.94 2.81 0.31 0.75 0.13
(92.2) (25.4) (54.1) (74.7) (71.4) (7.9) (19.1) (3.3)
A50P125 to 200 4, 4TA** 3, 4** 3.63 1.22 2.13 2.94 2.81 0.31 1.00 0.19
(92.2) (31.0) (54.1) (74.7) (71.4) (7.9) (25.4) (4.8)
A50P225 to 400 4, 4TA** 3, 4** 4.34 1.50 2.09 3.41 2.78 0.41 1.00 0.25
(110) (38.1) (53.1) (86.6) (70.6) (10.4) (25.4) (6.4)
A50P450 to 600 4, 4TA** 3, 4** 4.47 2.00 2.22 3.53 2.91 0.41 1.50 0.25
(114) (50.8) (56.4) (89.7) (73.9) (10.4) (38.1) (6.4)
A50P700 to 800 4, 4TA** 5, 6** 6.47 2.50 2.22 4.63 4.31 0.53 2.00 0.38
(164) (63.5) (56.4) (118) (109) (13.5) (50.8) (9.7)
A50P900 to 1200 4 3 6.97 3.00 3.22 4.97 *** 0.63 2.38 0.44
(177) (76.2) (81.8) (126) *** (16.0) (60.5) (11.1)
A50P Semiconductor Protection Fuses
Catalog No. Dimen. Fig. Catalog No. Dimen. Fig. Catalog No. Dimen. Fig.
A50P10-1 1 A50P175-4 3 A50P450-4 3
A50P15-1 1 A50P175-4TI 3 A50P450-4TI 3
A50P20-1 1 A50P200-4 3 A50P500-4 3
A50P25-1 1 A50P200-4TA 4 A50P500-4TI 3
A50P30--1 1 A50P200-4TI 3 A50P600-4 3
A50P35-4 2 A50P225-4 3 A50P600-4TA 4
A50P40-4 2 A50P250-4 3 A50P600-4TI 3
A50P50-4 2 A50P250-4TA 4 A50P700-4 5
A50P60-4 2 A50P250-4TI 3 A50P700-4TA 6
A50P70-4 3 A50P275-4 3 A50P700-4TI 5
A50P80-4 3 A50P300-4 3 A50P800-4 5
A50P90-4 3 A50P300-4TA 4 A50P800-4TA 6
A50P100-4 3 A50P300-4TI 3 A50P800-4TI 5
A50P100-4TI 3 A50P325-4 3 A50P900-4 3
A50P125-4 3 A50P350-4 3 A50P1000-4 3
A50P125-4TA 4 A50P350-4TI 3 A50P1000-4TI 3
A50P125-4TI 3 A50P400-4 3 A50P1200-4 3
A50P150-4 3 A50P400-4TA 4 A50P1200-4TI 3
A50P150-4TI 3 A50P400-4TI 3
* For ampere ratings and styles not listed, call Technical Services at 978-465-4853.
D10
Features/Benefits:
? Lowest I2
t of any fuse this size for greater protection
? Excellent cycling ability gives advantage in equipment design
? 600V AC / DC rated
A60Q Amp-Trap? Form 101 Semiconductor Protection fuses feature the only 600V
AC / DC rating in the industry of similar size (1-1/2” x 13/32”) fuses protecting
semiconductors. A60Q also has the lowest l2
t of all similar fuses and excellent
cycling ability. Applications include inverters and small equipment requiring extremely
fast response to faults, without the need to carry sustained heavy overloads.
Highlights:
? 600VAC/DC rated
? Extremely fast acting
? Current limiting
? Lowest I2
t
? Excellent cycling ability
Applications:
? Protection of small inverters and
drives, and equipment requiring
the highest degree of protection
Approvals:
? UL Recognized component
? AC: UL guide JFHR2
File E60314
Fuse Holders for A60Q Fuses ? DC: UL file E60314
USM Series .....UltraSafeTM Fuse Holders
303 Series .......Midget Fuse Blocks
1-1/2”
(38.1 mm) 13/32”
(10.3 mm)
A60Q Semiconductor Protection Fuses

 A 60 Q 30 - 2
Amp-Trap? Fuse
Rated Volts - 600

Style
Amperes*
Mounting Type
Ferrule, midget dims.
(1-1/2” x 13/32”)
A
60
Q
30
2
Catalog Numbering System
Catalog Numbers (amps)
* For ampere ratings and styles not listed,
call Technical Services at 978-465-4853.
 A60Q5-2 A60Q20-2
A60Q6-2 A60Q25-2
A60Q8-2 A60Q30-2
A60Q10-2 A60Q35-2
A60Q12-2 A60Q40-2
A60Q15-2
Ratings:
Volts : 600VAC / DC
Amps : 5 to 40A (AC)
: 5 to 40A (DC)
I.R. : 200kA I.R. AC
: 100kA I.R. DC
L/R : 10ms
D11
D
Features/Benefits:
? Low I2
t minimizes damage to protected components on short circuit
? Controlled arc voltage reduces stress to circuit components during fuse clearing
? Choice of mounting types helps in equipment design
A60X Amp-Trap? Form 101 Semiconductor Protection fuses are popular for the
protection of higher voltage heavy rectifiers such as traction rectifiers. They can carry
long sustained overloads common with heavy duty apparatus. 700A through 2000A
sizes are of compact, hockey-puck design, able to provide high power protection in a
small space.
Highlights:
? Fast acting
? Current limiting
? Low I2
t
? Indicator options available
Applications:
? Protection of heavy traction and
electrochemical as well as rectifiers
and other heavy-duty equipment
Approvals:
? UL recognized component
UL file E60314
? AC: UL guide no. JFHR2
(35-800A)
A60X Semiconductor Protection Fuses
Ratings:
Volts : 600VAC
Amps : 1 to 2000A
I.R. : 200kA I.R. AC

 A 60 X 600 - 4 TI
Amp-Trap? Fuse
Rated Volts - 600

Style
Amperes*
Mounting Types*
Ferrule
Blades, bolt-in
Hockey puck, bolt-in
Integral Blown-Fuse
Indicator
Trigger Indicator (see pg. J5)
Trigger Actuator (see pg. J5)
* For ampere ratings and styles not listed, call Technical Services at
978-465-4853.
A
60
X
600
1
4
128
TI
TA
Catalog Numbering System
Single Pole Fuse Blocks for A60X Fuses
Fuse Ampere Rating Fuse Block Catalog No.
1-30 60316
31-60 P243C
61-100 P243C
101-200 P243C
201-400 P266A
401-600 P266A
D12
Figure 2
Figure 1
Figure 8
Figure 3
Figure 5
Figure 6
Figure 7
Figure 4
A60X Semiconductor Protection Fuses
* For ampere ratings and styles not listed, call Technical Services at 978-465-4853.
Catalog Numbers (amps)
Catalog No. Dimen. Fig. Catalog No. Dimen. Fig. Catalog No. Dimen. Fig.
A60X1-1 1 A60X80-4TA 4 A60X400-4TA 4
A60X2-1 1 A60X90-4 3 A60X400-4TI 3
A60X3-1 1 A60X100-4 3 A60X450-4 3
A60X4-1 1 A60X100-4TA 4 A60X450-4TA 4
A60X5-1 1 A60X125-4 3 A60X500-4 3
A60X6-1 1 A60X125-4TA 4 A60X500-4TA 4
A60X7-1 1 A60X150-4 3 A60X500-4TI 3
A60X8-1 1 A60X150-4TA 4 A60X600-4 3
A60X10-1 1 A60X175-4 3 A60X600-4TA 4
A60X12-1 1 A60X200-4 3 A60X600-4TI 3
A60X15-1 1 A60X200-4TA 4 A60X700-4 5
A60X20-1 1 A60X200-4TI 3 A60X700-128 7
A60X25-1 1 A60X225-4 3 A60X800-4 5
A60X30-1 1 A60X250-4 3 A60X800-4TA 6
A60X35-4 2 A60X250-4TA 4 A60X800-128 7
A60X40-4 2 A60X250-4TI 3 A60X1000-128 8
A60X45-4 2 A60X300-4 3 A60X1200-128 8
A60X50-4 2 A60X300-4TA 4 A60X1500-128 8
A60X55-4 2 A60X300-4TI 3 A60X1600-128 8
A60X60-4 2 A60X350-4 3 A60X1800-128 8
A60X70-4 3 A60X350-4TA 4 A60X2000-128 8
A60X80-4 3 A60X400-4 3
* Optional Trigger Actuator (TA) or Trigger Indicator (TI)
Dimensions
Outline
Ref.
Mounting
Type
Fig.
Dimensions - Inches (mm)
Tap
A B C D E F G H
A60X1 to 30 1 1 5.00 .81 - - - - - - -
(127) (20.6) - - - - - -
A60X35 to 60 4 2 4.38 .81 2.78 3.69 3.44 .34 .72 .13 -
(111) (20.6) (70.6) (93.7) (87.4) (8.6) (18.3) (3.3)
A60X70 to 100 4, 4TI*, 4TA 3, 4* 4.41 1.00 2.91 3.72 3.59 .31 .75 .13 -
(112) (25.4) (73.9) (94.5) (91.2) (7.9) (19.1) (3.3)
A60X125 to 200 4, 4TI*, 4TA 3, 4* 4.41 1.22 2.91 3.72 3.59 .31 1.00 .19 -
(112) (31.0) (73.9) (94.5) (91.2) (7.9) (25.4) (4.8)
A60X225 to 400 4, 4TI*, 4TA 3, 4* 5.13 1.50 2.88 4.19 3.56 .41 1.00 .25 -
(130) (38.1) (73.2) (106) (90.4) (10.4) (25.4) (6.4)
A60X450 to 600 4, 4TI*, 4TA 3, 4* 5.13 2.00 2.88 4.06 3.69 .41 1.50 .25 -
(130) (50.8) (73.2) (103) (93.7) (10.4) (38.1) (6.4)
A60X700 to 800 4, 4TA* 5, 6* 7.25 2.50 3.00 5.94 4.56 .53 2.00 .38 -
(184) (63.5) (76.2) (151) (116) (13.5) (50.8) (9.7)
A60X700 to 800 128 7 4.00 3.00 3.75 2.50 1.50 - - - 3/8-24-1/2
(102) (76.2) (95.3) (63.5) (38.1) - - - Deep
A60X1000 to 1200 128 8 4.00 3.50 3.75 3.00 1.50 1.50 - - 3/8-24-1/2
(102) (88.9) (95.3) (76.2) (38.1) (38.1) - - Deep
A60X1500 to 2000 128 8 4.00 4.50 3.75 3.75 1.50 1.50 - - 1/2-20-1/2
(102) (114) (95.3) (95.3) (38.1) (38.1) - - Deep
D13
D
Features/Benefits:
? International 10 X 38 mm (1 1/2” X 13/32”) size for worldwide acceptance
? Ferrule mount 1 to 32A for design versatility
? Low I2
t for improved semiconductor protection
? gR Class according to VDE 636-23 and IEC 269.4
The 10x38 gR is a fast acting, full range fuse utilized in the protection of inverters,
UPS and other discrete semi-conductor devices
Highlights:
? Extremely fast acting
? Current limiting
? Low I2
t for improved
semiconductor protection
? Excellent cycling capability
? gR
Applications:
? Protection of small inverters, UPS
systems, motor drives and similar 700V
or less equipment
Approvals:
? UL recognized component
UL file E76491
? IEC 269-4 compliance
? AC: UL guide no. JFHR2
38mm (1.5")
10.3mm (.406")
10mm (.39")
10x38 gR Semiconductor Protection Fuses
Ratings:
Volts : 700VAC
: 500VDC
Amps : 1 to 32A
I.R. : 160kA I.R. AC
: 10kA I.R. DC
L/R : 10ms Body
Size
(mm)
Ampere
Rating
Rated
Voltage
(VAC)
Melting
I
2
t (A2
s)
Clearing I2
t
@ Rated
Voltage (A2
s)
Watts Loss
Description Catalog
No. @ 80%
Rated
Current
@ *
Rated
Current
10 X 38
1
700
0.17 0.48 0.4 0.8 FR10GR69V1 L1014563
1.25 0.17 0.55 0.8 1.5 FR10GR69V1.25 N1014565
1.5 0.31 0.8 0.6 1.5 FR10GR69V1.5 P1014566
2 0.94 2.5 0.7 1.3 FR10GR69V2 Q1014567
2.5 1.65 4.5 0.8 1.4 FR10GR69V2.5 T1014570
3 2.83 7.8 0.9 1.5 FR10GR69V3 V1014571
4 6.7 12 1 1.7 FR10GR69V4 W1014572
5 7.5 30 0.6 0.9 FR10GR69V5 X1014573
6 8.5 40 0.8 1.4 FR10GR69V6 Y1014574
8 5.4 35 1.1 1.9 FR10GR69V8 Z1014575
10 8.7 55 1.2 2.1 FR10GR69V10 A1014576
12.5 11 90 1.3 2.8 FR10GR69V12 C1014578
16 19 140 1.7 3 FR10GR69V16 D1014579
20 39 245 2.1 3.7 FR10GR69V20 E1014580
25 69 425 2.4 4.3 FR10GR69V25 F1014581
30 107 675 2.7 4.8 FR10GR69V30 G1014582
32 154 945 2.8 5.1 FR10GR69V32 H1014583
Catalog Numbers (amps)
D14
Features/Benefits:
? International 14x51mm (2”x9/16”) and 22x58mm (2-1/4”x13/16”) sizes for
worldwide acceptance
? Ferrule mount up to 100A for design versatility
? Very low I2
t for improved semiconductor protection
? 690V IEC rated, tested at 760VAC; can be used up to 750VAC in U.S.
? 700VDC rated for DC protection of equipment with L/R ≤10ms
? Superior cycling ability for longer life on difficult cyclic loading applications
? aR characteristic for semiconductor short- circuit protection
These Premium Amp-Trap? French cylindrical semiconductor fuses are an extension
of the popular A7OQS product line. They are solid-fill 14mm and 22mm fuses, IEC
rated 690VAC, 200kA Interrupting and 700VDC, 100kA interrupting at 10ms time
constant. In addition, these fuses have an 890 VDC rating for capacitor discharge
applications up to 2.5ms time constant. All ampere ratings are available with a striker.
Applications include small inverter drives and UPS systems, with superior l2
t for
improved protection and performance.
Highlights:
? 14 x 51 and 22 x 58 sizes
? 690VAC IEC rated
(760VAC max.)
? 700VDC rated
? Superior cycling ability
? Low watts loss
? Optional striker for visual/remote
Indication
Applications:
? Small inverters, UPS systems,
motor drives and similar 700V or
less equipment
Ratings:
Volts : 690VAC
: 700VDC
Amps : 6 to 100A
I.R. : 200kA I.R. AC
: 100kA I.R. DC
IEC : tested at 760VAC
Contact factory for details.
Approvals:
? UL recognized component
File E76491
? CSA Certified
? IEC 269-4 Compliance
Fuseholder -see Section H.
A70QS French Cylindrical

A 70 QS 20 14F I
Amp-Trap? Fuse
Rated Volts - 700
Style/Design
Amperes*
Size 14F= 14x51mm
 22F= 22x58mm
Optional Striker - I
Catalog Numbering System
A
70
QS
20
I
For the most current product performance data visit ep.mersen.com and use catalog search. D15
D
No Striker With Striker
Ratings and Application Data
*100kA, L/R = 11.6ms
A70QS French Cylindrical
Body
Size
(mm)
Ampere
Rating
Melting
I
2
t (A2
s x
103
)
Max Clearing
I
2
t @ 700VAC
(A2
s x 103
)
Watts Loss @
Rated Current
(W)
Catalog Number
